M-F3A PRO

Born to perform.

M-F3A Pro

Easy.
Compact.
Modular.

M-F3A PRO is a masterpiece of professional loudspeaker technology. With compact dimensions and unparalleled sound, the ultra-compact line array system is the perfect choice for all installations and mobile sound reinforcement.

It’s time to change the game …

Talk to us

Small cabinet.
Huge performance.

Whether in small rooms or large halls, for fixed or changing installations, as a groundstack or flown system – the M-F3A PRO line array is your reliable partner you can count on. Despite its small size, this perfect companion offers an incredibly powerful “signature sound” for any occasion. Ultra-compact self-powered line array system that offers ultra-clear sound reproduction with studio-quality mids and highs due to its hornless design.
Learn more
The integrated Class D power amplifiers with switch-mode power supply ensure maximum performance with minimum weight. The integrated rigging system and the intuitive operating concept are easy to use. This way you are well-equipped for any situation.
Set up.
Switch on.
Get started.

Perform everywhere.

Easily expandable.

The M-F3A PRO line array system is modular and scalable to any size. Events and installations for smaller groups or a crowd of several thousand listeners are no problem. The M-F3A PRO modules can also be easily combined with the M-Line or B-Line subwoofers.
Talk to us

Strong values.

The M-F3A PRO delivers exceptional sound quality that will thrill you. Experience the full range of sound, thanks to an extended frequency spectrum. Let the impressive performance convince you – for an unforgettable sound experience.

140 Hz – 20 kHz

Frequency Range

129 dB

Maximum Peak SPL

600 watts

Total Power

317 x 265 x 359 mm

Dimensions [H x W x D]

8.3 kg

Net weight

Connect power cable

Connect audio cables

Switch on

Select number M-F3A Pro

Set volume

  1. Connect power cable
  2. Connect audio cables
  3. Switch on
  4. Select number M-F3A Pro
  5. Set volume


Immediately ready for use.

Plug & Play, the M-F3A PRO system is ready for immediate use. Whether for installations or mobile sound reinforcement, the M-F3A PRO line array is designed to be easy to use and always deliver a superior listening experience. With just two controls, you can adapt the system to the environment and the application.
Talk to us

Perfectly equipped.

Each M-Line element is designed and manufactured by SE AUDIOTECHNIK. The unique features and carefully matched product portfolio allow you to operate and scale the system with minimal effort and resources. The easy handling and the customized amplifiers with ready-to-use DSP settings guarantee super-fast and persuasive results. Our M-Line speaker systems are available in both black and white.

M-F3A PRO

Flyable bass extension module with integrated amplifier and DSP.

M-F3A FS

12″ System subwoofer with integrated amplifier, DSP and 2-point rigging system.

S12 PRO

12″ System-Subwoofer mit integriertem Verstärker, DSP und 2-Punkt-Riggingsystem

S15 PRO

15″ system subwoofer with integrated amplifier, DSP and 2-point rigging system.
Mehr erfahren

Our subwoofers for even more bass

The B-Line – for a powerful foundation.

Good sound needs a powerful base. But every application is different and needs to be addressed individually. That’s why we have developed the B-Line into one of the most comprehensive and versatile subwoofer series on the market. Whether cardioid or end-fire setup, whether installation or mobile sound reinforcement, whether ground stack or flown line array – the B-Line provides the right Boooom.
Learn more

15“ – The space miracle

The most outstanding feature of the models with a 15″ woofer is their easy handling during setup and transport in combination with the impressive output power during operation. Note that this 15″ subwoofer is also available as a flyable version. So you also have plenty of bass in a flown system.

Size

15“

Voice coil

3“

max. SPL
up to 136 dB
Load capacity (passive)

1.600 W Peak

Power (self-powered)

800 W Class-D amp

18“ – The golden mean

The 18″ woofer, in conjunction with the powerful 4″ voice coil, delivers up to 138 dB max SPL and ranges down to 29 Hz. The passive B 18 is rated at 2,400 W (peak), while the self-powered subwoofers are driven by a 1,600 W Class-D amp. To transport and set up the basses in a quick and safe way anyway, there are two ergonomically optimized handles on each side.

Size

18“

Voice coil

4“

max. SPL
up to 138 dB
Load capacity (passive)
2.400 W peak
Power (self-powered)
1.600 W Class-D amp

21“ – The full load

The massive 21″ driver with its powerful 5″ voice coil thunders with up to 142 dB max. SPL down to the deepest depths – from 25 Hz it is the bass instance in our line-up. Powerful up to 4,000 W (peak), it delivers enough power for any stage and any event. Despite the higher weight, it is easy to maneuver thanks to the two well-positioned recessed grips on both sides.

Size

21“

Voice coil

5“

max. SPL
up to 142 dB
Load capacity (passive)
4.000 Watt peak
Power (self-powered)
1.600 W Class-D amp

Experience the M-F3A PRO in AR.

Thanks to augmented reality technology, you can view the M-F3A PRO in real space and get an in-depth idea of how it looks and feels in your environment. Just move your smartphone or tablet around the M-F3A PRO.
Scan the QR code and try it out.

3D-Modell ansehen

Download the Brochure

Discover more about our M-F3A PRO and dive into a special sound world.
Download

Jetzt Broschüre herunterladen

Entdecken Sie mehr zu unserer M-F3A PRO und tauchen Sie in eine besondere Klangwelt ein.
Download
