Portable Column
M-A6
M-A6 is an elegant, self-powered column system that blends seamlessly into corporate spaces, conference rooms, hotels, hospitality venues, houses of worship, and small to medium event locations. With plug-and-play operation, integrated DSP, Bluetooth audio and True Wireless Stereo (TWS), it delivers natural speech intelligibility and balanced musicality — from discreet background sound to confident performance levels — without dominating the room.
- Self-powered plug-and-play column system with integrated DSP
- Bluetooth audio and True Wireless Stereo for cable-free stereo operation
- Homogeneous near- and far-field coverage for speech and music
- Independent subwoofer level for quick room and programme tuning
- Discreet, durable design for corporate events, conferencing, hospitality, and houses of worship
Clear, even coverage: Multicell waveguide and carefully voiced three-way design deliver natural speech and balanced music — from the front row to the back.
Effortless connectivity, instant readiness: Plug-and-play operation with Bluetooth audio and TWS enables fast, flexible setups without additional hardware.
Robust elegance, purpose-built mechanics: Slim aluminium column, durable subwoofer base, and a secure locking interface for confident stability and quick assembly.
Technical details
| ACOUSTICAL DATA | |
|---|---|
| Model Name | M-A6 |
| Frequency range (-3 dB) | 50 Hz – 17 kHz* |
| Frequency range (-6 dB) | 45 Hz – 18 kHz* |
| Frequency range (-10 dB) | 40 Hz – 20 kHz* |
| Coverage angles (-6 dB) [H x V] | 130° × 20° |
| Maximum Peak SPL | 137 dB** |
| Continuous Maximum SPL | 124 dB** |
| System type | Self-powered column array system with integrated subwoofer |
| Crossover frequency | Low: 100 Hz, Mid 130 Hz, 2.5 kHz, Hi 2.5 kHz |
| Transducers | Low: 12" with 2.5" VC; Low-mid: 3.5" with 1" VC; High: 0.5" compression driver with 1" VC |
| Enclosure type | Low: bass reflex / ported; Low-mid: sealed column; High: multicell waveguide array |
| AMPLIFICATION | |
| Type | Class-D |
| Total power | 1000 W*** |
| Output power per channel | Low: 500 W, Low-Mid: 250 W, Hi: 250 W**** |
| Protection | Short circuit, temperature |
| Indicators | LEDs: ON (green), SIGNAL (green), LIMIT (red), PROTECT (red), BT PAIRING (blue), BT-TWS (blue) |
| Connectors | 1 × Line input, sym.; 1 × Line output, sym., buffered; powerCon® mains input twist connector |
| Wiring | N/A |
| Operating voltage range | 220–240 VAC, 4A; 100–120 VAC, 8A; 50/60 Hz; 800 W max. |
| Input sensitivity | 0 dBu |
| DSP | 48 kHz/24 Bit with extended dynamics, processing latency: 1.1 ms |
| Connectivity | Bluetooth® V.5.0, Profile: A2DP v1.3.1, AVRCP v1.6, A2DP codec: SBC, aptX, aptXHD |
| Processing | Crossover, Limiter, EQ, Level, low noise AD-DA |
| User controls | 2 × VRs: main volume, sub volume; 1 × push button: Bluetooth® pairing; 1 × push button: Bluetooth® TWS (pairing with second system for stereo Bluetooth®); 1 × power on/off switch |
| MECHANICAL DATA | |
| Product dimensions [H x W x D] | Subwoofer: 534 × 360 × 500 mm; Top column: 875 × 103 × 130 mm; Lower column: 713 × 103 × 130 mm; Total system height: 2030 mm |
| Net weight | Subwoofer: 23.3 kg; Top column: 6.8 kg; Lower column: 5.7 kg; Total: 35.8 kg |
| Packaging dimensions [H x W x D] | Subwoofer: 600 × 460 × 638 mm; Columns: 950 × 395 × 226 mm |
| Total weight | Subwoofer: 26.4 kg; Columns: 15.3 kg |
| Cabinet | Subwoofer: Plywood; Column: Aluminum; Column covers and connectors: ABS, Nylon, stainless steel |
| Cabinet finishing | Subwoofer: Polyurea coat; Column: Powder coat |
| Grille | Subwoofer: 1.5 mm steel, powder coated; Column: 0.8 mm steel, powder coated |
| ACCESSORIES | |
| Transport dolly | Plywood 18 mm, powder coated, four swivel wheels (two with brakes), butterfly connector to subwoofer. |
| Transport bag for columns | Padded, double layer Nylon, zipper, adjustable carrying strap |
| Transport/storage cover for subwoofer | Padded, double layer Nylon pull over cover, handle flaps |
| Flight case | Flight case for one column system |
| ANNOTATION | |
| * | Half space, -10 dBu / 7 m, SUB volume center position |
| ** | SPL/1m, half space, pink noise, 12dB crest factor, +10dBu input level |
| *** | Total power value is the sum of all individual channel output power |
| **** | According to EIA-426B Standard |
