M-Array
S12 PRO
Available in:Africa, Australasia, Caribbean, Central America, East Asia, EU, Europe, Middle East, North America, Oceania, South America, South Asia, Southeast Asia
Technical details
| Model Name | S12 PRO |
|---|---|
| ACOUSTICAL DATA | |
| Frequency range (-3 dB)* | 42 Hz – 99 Hz |
| Frequency range (-6 dB)* | 40 Hz – 135 Hz |
| Frequency range (-10 dB)* | 36 Hz – 145 Hz |
| Coverage angles (-6 dB) [H x V] | Omnidirectional |
| Maximum Peak SPL** | 132 dB |
| System type | 1-way active system |
| Crossover frequency | - |
| Transducers | 1 × 12" driver (3" voice coil) |
| Enclosure type | Vented box |
| AMPLIFICATION | |
| Type | Single channel, class-D with SMPS |
| Output power | 800 W |
| Protection | Short circuit, overheating, overcurrent |
| Connectors | Input signal: balanced XLR 3-pin female; Link output: balanced XLR 3-pin male; Power input: powerCON® 20A; Power link output: powerCON® 20A |
| Wiring | Pin N: Neutral; Pin L: Conductor; Pin E: Ground |
| Input sensitivity | 0 dBu |
| DSP | 48 kHz/24 bit with extended dynamics, processing latency: 1.1 ms |
| Processing | Factory and user presets, directivity control, EQ, delay, phase inversion |
| User controls | Power: ON/OFF switch; DSP: display with digital encoder |
| MECHANICAL DATA | |
| Product dimensions [H x W x D] | 507 × 385 × 495 mm |
| Net weight | 23 kg |
| Packaging dimensions [H x W x D] | 598 × 435 × 575 mm |
| Total weight | 24.8 kg |
| Cabinet | 15 mm plywood |
| Cabinet finishing | Black or white polyurea coating |
| Grille | Powder coated perforated steel |
| Hardware | Two side handles embedded in cabinet, 4 rubber feet and top slots for stacking, M20 pole thread |
| Stacking | Two-point SE Audiotechnik® stacking system |
| Splay angles | - |
| ACCESSORIES | |
| M-F3A S12 PRO SFi | Stacking frame for M-F3A PRO |
| SPS20 | Pole bar for S12 PRO |
| M-F3A S12 PRO FC | Flight case for S12 PRO |
| P801DL RC | Amplifier rain cover for S12 PRO |
| M-F3A S12 PRO TK 32 | Transport kart (6 units) for S12 PRO |
| ANNOTATION | |
| * | Measured with MF3AP preset |
| ** | Measured with 12 dB Crest factor Pink Noise, half space |
Packaging:
Cardboard outer packaging: 78.75% (1760 g) | Foam inner padding: 18.79% (420 g) | Plastic protective sleeve: 2.46% (55 g)
The following overview contains information on the regulated substances used in the product and on compliance with the applicable limit values.
"Lead (Pb): Used in printed circuit boards (printed circuit board | electronic components on the PCB | internal connecting wires | copper traces) (permitted exemption).
"
"Lead (Pb): Used in connectors (electrical connectors) (permitted exemption). "
Mercury (Hg): The content is not detectable or is below the applicable regulatory limits.
Cadmium (Cd): The content is not detectable or is below the applicable regulatory limits.
Hexavalent Chromium (Cr(VI)): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Biphenyls (PBB): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Diphenyl Ethers (PBDE): The content is not detectable or is below the applicable regulatory limits.
"Lead (Pb): Used in connectors (electrical connectors) (permitted exemption). "
Mercury (Hg): The content is not detectable or is below the applicable regulatory limits.
Cadmium (Cd): The content is not detectable or is below the applicable regulatory limits.
Hexavalent Chromium (Cr(VI)): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Biphenyls (PBB): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Diphenyl Ethers (PBDE): The content is not detectable or is below the applicable regulatory limits.
Environmental Protection Use Period: 15 year(s)
